Fixed LCD Display Gas Detector Transmitter Detect H2 Gas Leak Detector
Digital tube display H2 gas detector is with red high brightness and more intuitive scene show.It can be used separately as a gas detect instrument or can be connected to detection controller.It is with relay switch output signal and can add the explosion-proof lights or other external devices.
Size: | 144 mm * 190 mm * 91 mm |
Weight: | about 1130 g |
Destination gas: | H2 |
Measuring Range: | 0-1000ppm |
Alarm point: | 1ppm |
Response time: | ≤30s |
Working voltage: | DC24V |
Output signal: | 4-20MA |
Output way: | TWO or three wires |
Temperature range: | - 20 ℃ ~ 50 ℃ |
Humidity: | 15% ~ 90% RH (No condensation) |
Explosion-proof number: | CE101084 |
Explosion-proof marks: | Exd II CT6 |
Transmission distance: | <1000 m |
