1. Brief introduction:
Portable co gas detector is a special meter which is used to monitor the concentration of carbon monoxide in the air. This detector is small, portable, and easy to operate. It has become an best instrument for monitoring the air quality and ensuring the safety of people's lives.
The portable co gas detector consists of a sensor, display screen, and alarm system. The sensor is the core component of the detector, which plays an important role in detecting the concentration of carbon monoxide in the air. The display screen shows the concentration of carbon monoxide in real-time, and the alarm system will sound a warning when the concentration exceeds the safe level. The detector also has a replaceable battery, which provides power to the detector and can be replaceable when it is low.
The portable CO gas detector uses smart electrochemical sensors that can detect even low levels of CO gas and provide reliable and accurate readings in real-time. The detector has a simple and user-friendly interface that displays the CO level readings and alerts the users with visual and audible alarms when the gas concentration exceeds the safe limits.
2. Features:
1). LCD clear digital display;
2). Sensitive sensor element from UK;
3). Three alarms:lights, buzzer and vibration;
4). Detect CO gas concentration by natural diffusion;
5). 100% strictly inspection before package;
6). High Energy Li Battery for long time working,about 8 months,replaceable;
7). Shell adopts PC, high strength, heat resistance and corrosion resistance.
3. Technical parameters:
|
Name: |
Portable carbon monoxide co gas detector |
|
Size and net weight |
114*55*46mm, 105g |
|
Sensor type |
Electrochemistry method |
|
Sampling type: |
Natural Diffusion |
|
Destination gas |
carbon monoxide (CO) |
|
Measure range |
0-1000ppm,0-2000ppm resolution is 1ppm,others available |
|
Alarm points |
Low and high two alarm levels (can be set by user) |
|
Display |
LCD digital display |
|
Alarm |
Visible,audible,vibration |
|
Temperature range |
- 20 ℃ ~ 50 ℃ |
|
Humidity |
15% ~ 95% RH (No condensation) |
|
Battery type |
CR2 CR15H270 Li battery (Replaceable) |
|
Running time |
About 8 months, based on the environment in site |
|
Product type |
Explosion-proof |
|
Features |
With zero setting, alarm point set, can be calibrated,restore factory settings |
|
Certificates |
CE/ATEX/ISO9001/Cnex |
|
Warranty |
1year |
4. Application:
The portable co gas detector is used in many environments and industries, including workshops, factories, mines, and tunnels. Especially used in environments where there is a danger of exposure to carbon monoxide. The detector is also used in emergency response situations to detect carbon monoxide leaks and help rescue personnel evacuate safely.
5. Calibration:
To ensure the accuracy of the detector, it must be calibrated regularly. Manual calibration is a way of adjusting the detector's sensor and alarm settings. It requires a test gas and a calibration cup. The process involves measuring the concentration of carbon monoxide gas in the calibration gas, comparing it to the reading on the detector's display screen, and then set up the sensitivity of the sensor until it matches the concentration of the detection gas.
