Product Description:
This h2s gas detector can monitor gas concentration in air continuously and send signal to an optional alarm light or gas detection controller, when gas concentration exceed alarm value, it will make alarm
accordingly.
 |  |
Product specifications:
| Product Size: | 144*190*74mm |
| Product weight: | 1130g |
| Detect Gas: | H2S |
| Measure range: | 0-200PPM |
| Resolution: | 1ppm |
| Response time: | ≤30s |
| Working pattern: | continuous work |
| Working voltage: | DC24V |
| Output signal: | 4-20 mA |
| Options function: | Price including the audible & visual alarm lamp |
| Transmission cables: | three-wire system adopts three core shielded cable 3 x 1.5 mm2 |
| Features: | with relay output signal |
| Temperature range: | - 20 ℃ ~ 50 ℃ |
| Humidity | 15%-90%(RH) |
| Certificate: | CE,ATEX,ISO9001 |
| Explosion-proof marks: | Exd II CT6 |
| IP class: | IP65 |
| Transmission distance: | <1000 m |
Hydrogen sulfide gas transmitter features:
● with 4-20mA signal output,suitable for DCS,PLC controller
● with Relay output signal, can drive fan or solenoid valve
● CE,ATEX certificate, explosion proof
